Creo Parametric 10.0: Introduction to Mechanism Design

In the Creo Parametric 10.0: Introduction to Mechanism Design guide, you will learn how to simulate assembly motion in Creo Parametric using the Mechanism Design extension. You will also learn to set up your assemblies for motion and create animations of the assembly using the Design Animation option. This hands-on guide contains numerous practices.

Topics Covered:

• MDX interface
• Basic assembly connections
• Drag
• Snapshot configurations
• Joint axis settings
• Servo motors
• Motion playback
• Basic measure analysis
• Advanced connections
• Movie and image creation
• Design animation
• Key frame sequences
• Motion envelopes
• Trace curves
• Interference checks

Prerequisites:
• Access to the Creo Parametric 10.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
• It is highly recommended that you have completed the Creo Parametric: Introduction to Solid Modeling or Creo Parametric: Advanced Assembly Design and Management guides or have similar levels of prior experience using the Creo Parametric software.

ASCENT eBooks are delivered through the VitalSource Bookshelf e-textbook platform. This format enables you to access your eBook in the following ways:

1. Download to a computer (Windows or MAC)
2. Access online (via a computer connected to the internet)
3. Download to a compatible smart phone or tablet device

Please Note:

• Dual monitors or separate reader device recommended to facilitate use with software.
• eBooks are intended for single-user use only. License restrictions prevent multi-user or network access.
• eBook is not a printable PDF and intended for electronic use only.
• eBooks cannot be returned if license code has been redeemed.

Visit: bookshelf.vitalsource.com to learn more

Instructor Tools are delivered in a downloadable PDF document containing presentation files that complement the guide. In the order confirmation email, click on ‘Instructor Tools’ (found under the ‘Product’ heading) to gain access to your PDF.
