The Creo Parametric 10.0: Sheet Metal Design guide enables you to use your introductory modeling skills to create sheet metal models, including walls, bends, notches, and form features. On completion of this guide, you will have acquired the skills to confidently manipulate sheet metal geometry, adjust bend developed lengths, and convert solid parts.
This guide was developed against Creo Parametric 10.0.3.0.
Topics Covered:
• The sheet metal environment
• Primary and secondary walls
• Bend relief
• Corner relief
• Regular unbends, back bends, and cuts
• Notches and punches
• Bend features
• Unbending complex geometry
• Sheet metal forms
• Documenting a sheet metal part
• Converting solid parts
• Sheet metal setup
• Investigating a sheet metal part
Prerequisites:
• Access to the Creo Parametric 10.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
• Completion of the Creo Parametric: Introduction to Solid Modeling guide, or similar levels of prior experience using the Creo Parametric software.
ASCENT eBooks are delivered through the VitalSource Bookshelf e-textbook platform. This format enables you to access your eBook in the following ways:
- Download to a computer (Windows or MAC)
- Access online (via a computer connected to the internet)
- Download to a compatible smart phone or tablet device
Please Note:
- Dual monitors or separate reader device recommended to facilitate use with software.
- eBooks are intended for single-user use only. License restrictions prevent multi-user or network access.
- eBook is not a printable PDF and intended for electronic use only.
- eBooks cannot be returned if license code has been redeemed.
Visit: bookshelf.vitalsource.com to learn more
Instructor Tools are sold separately from the Learning Guide.
Once you have completed your purchase, you’ll receive an order confirmation email with a link to access the Instructor Tools. Within that email, click on ‘Instructor Tools’ (found under the ‘Product' heading) to gain access to your PDF.
