The Creo Parametric 11.0: Design Documentation and Detailing guide is designed for all draftspersons who document designs using Creo Parametric. It focuses on how to use Creo Parametric to communicate design information from your part and assembly models.
This content was developed using Creo Parametric 11.0, Build 11.0.1.0.
Topics Covered
• View creation
• View manipulation
• Detailing a drawing
• Drawing notes
• Tolerances
• Assembly drawings
• Drawing tables
• 2D sketching
• Symbols
Prerequisites
• Access to the Creo Parametric 11.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
• Completion of the Creo Parametric: Introduction to Solid Modeling guide or similar levels of prior experience using the Creo Parametric software.
ASCENT eBooks are delivered through the VitalSource Bookshelf e-textbook platform. This format enables you to access your eBook in the following ways:
- Download to a computer (Windows or MAC)
- Access online (via a computer connected to the internet)
- Download to a compatible smart phone or tablet device
Please Note:
- Dual monitors or separate reader device recommended to facilitate use with software.
- eBooks are intended for single-user use only. License restrictions prevent multi-user or network access.
- eBook is not a printable PDF and intended for electronic use only.
- eBooks cannot be returned if license code has been redeemed.
Visit: bookshelf.vitalsource.com to learn more
Instructor Tools are presentation files (downloadable as PDFs) designed to complement ASCENT learning guides. Sold separately from the learning guides and eBooks, Instructor Tools serve as an excellent support resource for software instructors.
