3DEXPERIENCE SIMULIA 2023x: Linear Structural Validation

Number of Pages

374

Total Hours

16

Select Format

Learning Guide (Print), Learning Guide (eBook), Instructor Tools

The 3DEXPERIENCE SIMULIA 2023x: Linear Structural Validation guide covers the fundamentals of the Linear Structural Validation (LSV) app. It provides you with the knowledge to effectively use 3DEXPERIENCE 2023x for structural finite element analysis and simulation, thereby reducing design time. This is an extensive hands-on guide, which enables you to apply your knowledge through real-world scenarios and examples.

Topics Covered:
• Introduction to 3DX simulation
• Basic structural simulation
• Loads and boundary conditions
• Mesh refinement
• Assembly analysis
• Fasteners
• Frequency analysis
• Buckling analysis
• Thermal Analysis

Prerequisites:
• Access to the 3DEXPERENCE CATIA 2023x version of the software, to ensure compatibility with this guide. Future software updates that are released by Dassault Systèmes may include changes that are not reflected in this guide. The practices and files included with this guide might not be compatible with prior versions (i.e., 3DEXPERENCE CATIA 2022x).
• Completion of the 3DEXPERENCE CATIA 2022x: Introduction to Modeling course or equivalent CATIA experience is recommended. Any knowledge of FEA is beneficial but is not a mandatory requirement.

ASCENT eBooks are delivered through the VitalSource Bookshelf e-textbook platform. This format enables you to access your eBook in the following ways:

  1. Download to a computer (Windows or MAC)
  2. Access online (via a computer connected to the internet)
  3. Download to a compatible smart phone or tablet device



Please Note:

  • Dual monitors or separate reader device recommended to facilitate use with software.
  • eBooks are intended for single-user use only. License restrictions prevent multi-user or network access.
  • eBook is not a printable PDF and intended for electronic use only.
  • eBooks cannot be returned if license code has been redeemed.



Visit: bookshelf.vitalsource.com to learn more

Instructor Guides are ideal teaching resources that incorporate the following instructional tools within the learning guide: answers to the chapter review questions, suggested timing guide for course delivery, and instructor presentation files.
